AC Power
Accessories
DDT16
Screw terminal for 'V' connection
DDT16
Part Number
400132
Availability:
€7.00 (excl. tax)
Add to cart
Shipping is only available to France.
OK
Available within 3 weeks
'V' connection screw terminal for SPD
Improved connection for better efficiency
2 x 35 mm² wire connection
Adapted to DAC/DDC surge protectors
Datasheet
Installation Sheet
Tender specifications
Contact Us
The DDT16 is a terminal adapter that transforms a screw terminal into a double terminal to connect an incoming and an outgoing cable, with a maximum section of 35 mm² per conductor. This product is intended for CITEL's DAC/DDC ranges.
Select another reference:
DDT16
DSDT16
Electrical Properties
Mechanical Properties
Norms
Schemas
Max. load current
@25°C
IL
100 A
Mounting
On DAC/DDC range terminal
Housing material
Polycarbonate UL94 V-0
Dimensions
See diagram
Contacts
Brass
Mini-max. cross section
2.5 - 35 mm² (13-2 AWG)
Torque
2-2.2 Nm (18-22 lb-in)
Weight
0.042 kg
Standards compliance
UL1059
×
Description:
Screw terminal for 'V' connection
Standards compliance:
UL1059
CITEL
Reference:
DDT16
Part Number:
400132
Or equivalent
