Surge and Electrostactic protector for Class II LED lighting system

MLPC2-230L-V/ESP2
Part Number 832227
MLPC2-230L-V/ESP2
Availability:
€27.00 (excl. tax)
Add to cart
  • Type 2 (or 3) Surge & Electrostatic protectors
  • For Class II Led lighting
  • Improved coordination with internal MOV
  • Electrostatic protection included
  • Comply class II safety rules
  • Very compact
  • Plate mounting
  • Screw terminal connection
  • Status indicator
  • End of life AC Disconnection
  • IEC 61643-11 and EN 61643-11 compliance
Contact Us
Select another reference:
SPD type
2+3
Isolation classe
 II
Network
 220-240 V Single-phase
AC system
 TT-TN
Max. AC operating voltage
Uc 320 Vac
Max. load current
@25°C
 IL 5 A
Temporary Over Voltage (TOV) Characteristics - 5 sec.
Without disconnection
 UT 335 Vac withstand
Temporary Over Voltage (TOV) Characteristics - 120 mn
Without disconnection or with safety disconnection
 UT 440 Vac disconnection
Residual Current
Leakage current to Ground
 Ipe None
Nominal discharge current
15 x 8/20 µs impulses
 In 5 kA
Max. discharge current
max. withstand @ 8/20 µs by pole
 Imax 10 kA
Total Maximum discharge current
max. total withstand @ 8/20 µs
Imax Total 20 kA
Withstand on Combination waveform IEC 61643-11
Class III test: 1.2/50µs - 8/20µs
 Uoc 10 kV
Withstand on overvoltages IEEE C62.41.1
 10 kV / 10 kA
Protection level
@ In (8/20µs)
 Up 1.5 kV
Admissible short-circuit current
 Isccr 10 000 A
Electrostatic protection level
 Uesp > 0.5 kV
Electrostatic protection mode
 N/Functional Earth
Connection to Network
 2 screw terminals opposite side in/out - wire 2.5mm² max.
Mounting
 On plate
Housing material
 Thermoplastic UL94 V-0
Operating temperature
 Tu -40/+85°C
Protection rating
 IP20
Failsafe mode
 Disconnection and AC line cut-off
Disconnection indicator
 LED green OFF and AC network cut-off
Voltage/operating indicator
 Green Led ON
Dimensions
 See diagram
Weight
 0.042 kg
Standards compliance
 EN 61643-11 / IEC 61643-11
Certification
Thermal disconnector
 Internal
Installation ground fault breaker
 Type 'S' or delayed
